BIG NEWS FOR BIG PRESENTATIONS

Introducing the first-ever 3LCD WUXGA projector

Epson brings you the new WXGA Epson EB-Z8050W, which features 7000 lumens, dual lamp system and 3LCD technology suitable for any large venue or event.

Bringing together 3LCD and optical technology

Epson brings 20 years of technology to a unique range of high brightness projectors. All 3LCD projectors use a 3-chip, solid-state optical engine to deliver incredibly bright, true-to-life colour, creating an astonishing level of realism. The three colour images are combined using a prism to form

a full-colour image consisting of millions of colours. With pure 3LCD plus the powerful 7000 lumens dual lamp system, you enjoy the best picture quality and projector performance.

Colour Light Output, the new metric for projector brightness

Epson provides Colour Light Output specification data. Colour Light Output measures a projector’s ability to deliver colour, providing users with a simple, accurate and easy way to evaluate projector colour performance.

Outstanding quality, impressive size

The EB-Z8050W has 1280 x 800 pixels, and features Epson’s most advanced C²Fine (Crystal

Clear Fine) 3LCD inorganic panels with an inorganic alignment layer and vertically aligned liquid crystal. The result is smooth and uniform images with perfect contrast for high image quality.

Get superb digital cinema colour

When the Epson Cinema Filter technology, the Epson EB-Z8050W colour space even covers the DCI colour standard used in digital cinema, enabling accurate and faithful reproduction of colour content the way film producers originally intended.

See the difference

Epson’s innovative optical technology delivers exceptional picture quality and the projector’s auto iris brings out every shade of contrast. In addition, the colour light output of 7000 lumens and 5,000:1 contrast ratio give great greyscale for small print and figures as well as shadows and light.

The EB-Z8050W is versatile. It can be used for digital content from spreadsheets and business applications to CAD graphics, Flash animations, HDTV, HD video and multi-screen presentations. You can even use it indoors and outdoors, even in daylight.

• Bringing together 3LCD and optical technology
• Colour Light Output, the new metric for projector brightness
• Outstanding quality, impressive size
• Get superb digital cinema colour
• Ideal for ceiling mounted installation
• More flexible features
• Tough, reliable and increasingly energy efficient
• Lens not included - Choose from 5 optional lenses

Technical specification:

What's In The Box: Power cable: 3 m, 3 Wire, Computer cable: 1.8 m D-sub 15pin D-sub 15pin, Remote control, User manual: 25 languages, Password protect sticker, Cable cover, Lens release button lock screw: Included with lens, Lens cover , Wireless LAN adapter (ELPAP03)
Projection System 0.95-inch wide inorganic panel with MLA (x3) TFT
Projection Lens Focus Zoom Type Standard lens: Powered focus / powered zoom
Screen Size Standard lens: 60 - 500 inch
Lens Shift Standard lens:, Vertical: ±70%, Horizontal: ±20%
Projection Distance (120’’ on 16:10 screen) 4.50 m - 7.30 m
Lens 6 optional lenses
Throw Ratio Standard lens: , 16:9 and 16:10 aspect ratios: 1.71 - 2.78, 4:3 aspect ratio: 2.05 - 3.33
Light output White light output* - High: 7000 ANSI lm, White light output* - Normal / Eco: 5600 ANSI lm, Colour light output - High: 7000 ANSI lm, Colour light output - Normal / Eco: 5600 ANSI lm, * ISO 21118 based
Projection Lens F Number Standard lens: 1.65 - 2.51
Projection Lens Focal Length Standard: 36.00mm, 57.35mm
Frequency RangeHorizontal: 15 - 80 kHz, Vertical: 50 - 85 Hz
Projection Lens Zoom Ratio Standard lens: 1 - 1.61
Resolution WXGA (1280 x 800) / native aspect ratio 16:10
High Definition 480i / 576i / 480p/ 576p / 720p / 1080i / 1080p
Contrast Ratio * 5000:1 (auto iris on), * ISO 21118 based
Lamp Hours 3500 hours / 2500 hours (eco / normal brightness mode)
Lamp Type 330 W UHE x 2
Keystone Correction With standard lens , Vertical: -30 degrees to +30 degrees (zoom: tele), Horizontal: -20 degrees to +20 degrees (zoom: tele)
Colour Reproduction Full-colour (16.77 million colours)
Colour Video Processing 3D Y/C separation, noise reduction
Cinema Filter Digital Cinema Colour (DCI)
Input Video 1 x D-sub 15-pin (component), 1 x RCA, 1 x S-video, 1 x 1-BNC
Input Computer 1 x D-sub 15-pin (RGB), 1 x 5-BNC, 1 x DVI- D
Input USB Display Memory Device 1 x USB type B for computer input
Input HDMI 1 x HDMI, 1 x DVI-D
Control 1xRS-232C
Network 1xRJ45 (LAN)
Networking and Wireless Features Projector control and projector management via network (wireless or wired LAN)
Direct Power On/Off Lens ProtectionLens cover cap
Security cable hole, Kensington lock
On Screen Menu 27 languages
Dimensions D x W x H Excluding feet: 734 x 534 x 167 mm (not including foot, projection lens and handle), Maximum dimension: 734 x 534 x 225 mm
Weight Approx. 46.2 lbs. / 22 kg (including lens)
Operating Temperature 0°C to 45°C
Operating Altitude 0 m to 3, 048 m (high altitude mode over 1500 m)
Software EasyMP Monitor (for Windows), Epson projector control software (for Windows, web download only)
Power Consumption Lamp On 877 W / 734 W (normal / eco mode)
Power Consumption Stand By 13.1 W (network on) / 0.5 W (network off)
Power Supply 100 - 240 V AC ±10%, 50/60 Hz
Noise Level 32 dB / 38 dB (eco / normal)
